Edgebanders

Semi Automatic machine controlled by a PLC with inverter for trimming corners on panels. Trimming machine for straight and curved panels, edged in veneer, melamine, PVC or ABS, with a thickness of up to 3mm High frequency Motor 12000 rpm, 0.37 kw controlled by an inverter Panel Thickness 16mm - 52mm Minimum Internal Radias 21mm Weight 210kg Cycle initiation by foot pedal Corner blending of 3mm PVC and soft / post form profiles Safety and noise reduction cabin Roller support table Following wheel independent from cutter to prevent marking of workpiece  Youtube Video Demo:   https://youtu.be/KLCjiWUC29k

Working Length                        350-1850mm Working Width                           50-800mm Working Thickness                   10-50mm Max Weight                                 1500kg Max Speed of Workpiece         25mt/min     Youtube Video Demo:

Workpiece length                                   250~2400mm Workpiece width                                    50~700mm Workpiece thickness                             10~40mm Max. Workpiece Capacity                    1500kg Max. speed of working                          25m/min     Youtube Video Demo:

High production European Edge Bander with gluing of edging, edge trimming front and back + top and bottom, scraping, radius trimming and buff polishing.     Large cost saving as compared to new, new SCM Olimpic approx. R389 000    Pre-owned machine sold fully checked, serviced and in excellent working condition Automatic Edge Bander with High Frequency Motors  Efficient High-Quality Machining.  Advantages Include:  Automatic Adjustment of All the Units When the Panel Thickness Is Changed  Excellent Fluing Using Hot Melt Glue  Accurate And Precise Machining With 12,000 Rpm Motors  Maximum Strip Edging Thickness 5mm  End Trimming Units with Two Independent Motors Sliding on Prism Guides.  Can Be Tilted From 0 – 15 Degrees, Manually or From the Control Panel.  Edge Trimming Unit  Moves On Ground Guides with Re-Circulating Ball Screws Bushes.  Front And Side Copiers and Digital Mechanical Indicators.    Scarper Unit  Brushing Unit    Working Thickness 8 – 40 Mm  Strip Edge Thickness 0 – 4.5mm  Minimum Panel Width 60mm  Minimum Panel Length 140mm  Feed Speed 8 M/Min  Dimensions: 3935 (L) X 1295 (H) X 1645 (W)     Youtube video : Available on request

High quality pre-owned machine sold fully checked, serviced and in excellent working condition Machine is sold with 3-month quality guarantee attached  Glue pot fully refurbished  The T-EB 156 can easily operate at a speed of 12 mt / min and can apply all popular edge materials (PVC, ABS, Melamine, Veneer, Solid wood, etc.) to all types of panels up to 3 mm edging thickness with high precision.   Pre-milling  Contour trimming top/bottom/front/back  Corner rounding  Radius scraping  Buffing    TECHNICAL DETAILS Edge Material Thickness: 0,4 – 3 mm Board Thickness: 10 – 46 mm Speed: 12 mt / min Total Electrical Power: 10,2 kW Total Air Pressure: 6 bar Total Air Usage: 230 lt / min Working Height: 870 mm Buffing Motor: 2 x 0,18 kW 1400 rpm Front Milling: 2 x 1,5 kW 12000 rpm Trimming: 4 x 0,37kW 12000 rpm Machine Width: 920 mm Machine Length: 4500 mm Machine Height: 1600 mm Machine Weight: 1680 kg    Youtube video : https://youtu.be/zO0hSyxVj50

Milling Machine T-FC 198 opens profiles on the edges of MDF, Chipboard etc. panels in order to make them ready prior to postforming and soft forming applications. The machine consists of conveyer unit, 2 pieces profiling cutter heads, grooving saw and speed adjustment feature. Direct-Drive milling motor.    High-quality Pre-Owned machine sold fully checked, serviced, and in excellent working condition The machine is sold with a 3-month quality guarantee attached    | Board Thickness              | 10 - 50 mm     |  | Speed                       | 2 - 11 m/dk - m/min |  | Total Electrical Power       | 10 kW          |  | Working Height               | 880 mm         |  | Cutter Rotation              | 4500 Rpm       |  | Milling Motor Power          | 2x4 kW         |  | Trimmer Knife Insert Dimens. | 30 (Çap/Diameter) |  | Grooving Saw                 1,1 kw / 2800 Rpm |  | Dust Collector Enter         | 125 mm (Çap/Diameter) |  | Machine Dimensions           | 920x3300x1600 / 1075kg     Youtube video : Available on request

High-quality Pre-Owned machine sold fully checked, serviced, and in excellent working condition The machine is sold with a 3-month quality guarantee attached Automatic Edge bander with Pre-milling, magazine, glue station, pressure zone, front and rear snipping, Rough Trimmers, Fine Trimmers, Scrapers and buffers. Panel Thickness 10-60mm Panel Width Min 80mm Panel Length Min 160mm (PVC) Edge Width 15-65mm Edge Thickness 0.4-15mm Feed Speed 9-18 mt/min Frequency Converter 200Hz Installed Power 12.18kw Pneumatic Power 0.7MPa Net weight 1750kg Overall Dimensions estimate 4765x850x1380mm  YouTube Video Demo: https://youtu.be/Vl3HT4ExHUo
