Lathes in stock and immediately Available

All machines below are in stock and available right now at our premises in Johannesburg, South Africa. 🇿🇦
Come visit our showroom or request an online demo video.
All machines are sold serviced, reconditioned and carry a quality guarantee unless otherwise specified.

  • High quality pre-owned machine sold fully checked, serviced and in excellent working condition High quality European machine from Italy Max. distance between centres mm. 1200 Height of centres over bed mm. 120 Max. copying diameter mm. 150 (106) Max. diameter permitted by travelling steady mm. 90 (65) Connection for driving and tailstock centre CM 3 Saddle feed speed 0 ÷5 mt/min. Saddle return speed 5 mt/min.     Youtube Video Demo:     https://youtube.com/shorts/uFcGatWL6og
  • -           Fully checked, serviced and in excellent running condition. -           1200mm maximum length of component -           Voltage:380 volts,3 phase 50hz
  • Hydraulic Face Base Plate Bowl Frontal Lathe And Combi Versatility Between Centers. This Lathe is Designed And built For Maximal Flexibility To The Woodturners, Keeping Two Operations Task in One machine. To obtain the best for end-=product for All Types Of Bases, Bowls, Dishes, Rings, Rosettes And All Types Of Columns. The Machine uses Two Copy Hydraulic Tracers Following A Template Contour, One Copy On the Frontal Edge and the Second Copier On the Outside Edge Profile. All Movements Are Hydraulically Operated. The electric Spindle Motor Is equipped with an Electric Break To Give A Rapid Change of workpieces for the operator. Maximum Length Of Turning 900mm Maximum Diameter Of Turning Without Stay 600mm Spindle Motor Power + Break 5 Kw Speeds 800/1600/2400/3500/4200/5400/6000 Rpm Pump Motor Power 2kw Vacuum Pump 1 Kw Hydraulic Tool Holder 2 Stroke Cylinder Counterpoint 300mm Electro break 1 Dust Extraction Outlet 100mm Diameter Weight 1800 Kg Dimensions 1300 (W) X 1800mm (H) 2900mm (L) Hydraulic Back Knife Tool Holder Rotation Motor 8.5 kW  Youtube Video Demo: available on request
  • High quality pre-owned machine sold fully checked, serviced and in excellent working condition 3 month quality guarantee as per our T’s and C’s. 1.1kw motor, 3 phase Can turn up to 500mm diameter 3 Speed pulley system   Youtube Video Demo:
  • Pre-owned machine sold fully checked, serviced and in excellent working condition 3 month quality guarantee as per our T’s and C’s. Max work piece length 1300mm between centres Motor Power 380V 5HP Variable hydraulic feed speed 1500 – 2000 – 3000 – 4000 Rpm Dimensions 3000mm (L) x 1160mm (W) x 1210mm (H)    Youtube Video Demo:
  • 380volt Max work piece length: 1000mm between centres Three Back knives Voltage: 380 volts, 3 phase, 50hz

Lathes in stock and immediately Available

All machines below are in stock and available right now at our premises in Johannesburg, South Africa. 🇿🇦
Come visit our showroom or request an online demo video.
All machines are sold serviced, reconditioned and carry a quality guarantee unless otherwise specified.

  • High quality pre-owned machine sold fully checked, serviced and in excellent working condition High quality European machine from Italy Max. distance between centres mm. 1200 Height of centres over bed mm. 120 Max. copying diameter mm. 150 (106) Max. diameter permitted by travelling steady mm. 90 (65) Connection for driving and tailstock centre CM 3 Saddle feed speed 0 ÷5 mt/min. Saddle return speed 5 mt/min.     Youtube Video Demo:     https://youtube.com/shorts/uFcGatWL6og
  • -           Fully checked, serviced and in excellent running condition. -           1200mm maximum length of component -           Voltage:380 volts,3 phase 50hz
  • Hydraulic Face Base Plate Bowl Frontal Lathe And Combi Versatility Between Centers. This Lathe is Designed And built For Maximal Flexibility To The Woodturners, Keeping Two Operations Task in One machine. To obtain the best for end-=product for All Types Of Bases, Bowls, Dishes, Rings, Rosettes And All Types Of Columns. The Machine uses Two Copy Hydraulic Tracers Following A Template Contour, One Copy On the Frontal Edge and the Second Copier On the Outside Edge Profile. All Movements Are Hydraulically Operated. The electric Spindle Motor Is equipped with an Electric Break To Give A Rapid Change of workpieces for the operator. Maximum Length Of Turning 900mm Maximum Diameter Of Turning Without Stay 600mm Spindle Motor Power + Break 5 Kw Speeds 800/1600/2400/3500/4200/5400/6000 Rpm Pump Motor Power 2kw Vacuum Pump 1 Kw Hydraulic Tool Holder 2 Stroke Cylinder Counterpoint 300mm Electro break 1 Dust Extraction Outlet 100mm Diameter Weight 1800 Kg Dimensions 1300 (W) X 1800mm (H) 2900mm (L) Hydraulic Back Knife Tool Holder Rotation Motor 8.5 kW  Youtube Video Demo: available on request
  • High quality pre-owned machine sold fully checked, serviced and in excellent working condition 3 month quality guarantee as per our T’s and C’s. 1.1kw motor, 3 phase Can turn up to 500mm diameter 3 Speed pulley system   Youtube Video Demo:
  • Pre-owned machine sold fully checked, serviced and in excellent working condition 3 month quality guarantee as per our T’s and C’s. Max work piece length 1300mm between centres Motor Power 380V 5HP Variable hydraulic feed speed 1500 – 2000 – 3000 – 4000 Rpm Dimensions 3000mm (L) x 1160mm (W) x 1210mm (H)    Youtube Video Demo:
  • 380volt Max work piece length: 1000mm between centres Three Back knives Voltage: 380 volts, 3 phase, 50hz
